5.6Mpa Fm200 Gas Suppression System With 120L Storage
Parameter:
| No. | specification | Technical Parameter |
| 1 | Filling pressure | 5.6Mpa |
| 2 | Scale of Protective region for one zone | area:max single-zone is 800m² volume:max single-zone is 3600m³ |
| 3 | Spraying time | ≤10s |
| 4 | Filling density | ≤1080kg/m3 |
| 5 | power | DC24V/1.6A |
| 6 | Nitrogen Pressure of Driving Device | 6.0±1.0Mpa(20℃) |
| 7 | Condition of reserving room for container | temperature: -10~50℃, relative humidity: ≤97% |
| 8 | max working pressure | 8.0Mpa |
| 9 | min working pressure | 4.6Mpa |
Description:
FM200 gas is a clean, colorless, and environmentally friendly fire
suppression agent that quickly extinguishes fires without leaving
any residue or damaging the protected assets.
The FM200 gas suppression system is designed to detect fires and
release the FM200 gas only in the affected area. The gas acts
quickly to reduce the oxygen levels, while breaking down the free
radicals that initiate the combustion process, thereby stopping the
fire in its tracks.
These systems are highly effective in data centers, electrical
rooms, control rooms, libraries, archives, and other areas with
sensitive equipment or valuable assets.
In addition to being environmentally friendly, FM200 gas
suppression systems are also safe for human occupancy and leave no
cleaning residue. They are easy to maintain and can be integrated
with building management systems to provide remote monitoring and
control.
1. Totally automatic system
2. Accurate control of protection zone
3. No need for employment of monitor staff
4. Manual or electromagnetic manipulation and mechanical
manipulation
5. Direct target to expensive machine or delicate device
6. Short time discharge of extinguishing agent
7. Preparation for storage room
8. Space confirmation of placement for cylinder group
Applications:
Electronic computer room, a data processing center,
telecommunications facilities, process control, expensive medical
equipment, industrial equipment, library, museum and art gallery,
clean room, anechoic chamber, emergency power facilities, flammable
liquid storage area, etc.
Competitive advantage:
1. clean gas agent
2. colorless, tasteless, low toxicity, and non-conductive
3. no residue or oily deposits
4. small storage space and easily pressurized in cylinder
5. compliance with environmental protection requirement
6. Large range of application area
7. perfect protection of apparatus or zones
8. no damage to equipment or device
9. simple disposal after ventilation
Company Introduction
Guangzhou Xingjin Fire Equipment Co., Ltd., surrounded by
convenient transportation and beautiful environment, is located in
Guangzhou, which plays an important role in communication between
China and the world. We are a manufacturer, and we devote ourselves
to the study and development of HFC-227ea (FM200) productions with
our professional and mature team including the program design team,
the skillful installation team, the quality detecting team and the
after-sell service team. Nowadays, our popular fm200 products are
widely used, such as the pipe network FM200 fire suppression
system, the cabinet type FM200 fire suppression system, the
automatic FM200 fire extinguisher
(ceiling mounted style), the fire detecting tube suppression system
and automatic fire suppression tube. As a result of high-quality
products and services as well as the good reputation, our company
is well-received by the customers in China.
Why Choose Us
• 5 years quality guarantee
• Xingjin is running in a high efficiency management system
• Advanced equipments & professional engineers to promise all
products are quite satisfactory.
• We provide 8×6 hrs technical support and service.
After-Sale Service
• We have an efficient sales and after sales team to promise slove
all client's question in time.
• We provide 8×6 hrs technical support and service.
FAQ
Q1: Are you a manufacturer or a trading company?
A1: We are a manufacturer.
Q2: Is OEM products available?
A2: Yes, we welcome your own design and drawing.
Q3: Where is your factory? Can I visit it?
A3: Our factory locates in Shilou, Panyu, Guangzhou, Guangdong,
China.
Of course yes. We always welcome and wait for your visit.
Q4: How can I get to your factory?
A4: Because of the convenient transportation here, you can take a
taxi or come here by subway. If you come here by subway, you need
to take the line four and get off at Shiqi station. Then walk out
the station for taking No. 126 bus and get off at Yuexi station.
